- Regular Tipping Grid
- MOBILITY: Track
- ENGINE: CAT 4.4 T4
- SCREEN : 11x5 Double Screen Box
- FULLY SERVICED
- FULL WARRANTY
- CERTIFIED POWERSCREEN
- HOURS: 300
- PRICE: $365,000.00
- DOUBLE YOUR PRODUCTION
2018 Powerscreen Chieftain 2200 Track
Check out the 2018 Powerscreen Chieftain 2200 Track
specifications and features.
| CHIEFTAIN 2200 | WITH GRID | WITH DOUBLE DECK VIBRATING GRID |
| Weight (Est) | 35, 350kg (78,000lbs) | 39,350kg (86, 750lbs) |
| Transport width | 3m (9' 10") | 3m (9' 10") |
| Transport length | 19.79m (64' 11") | 19.79m (64' 11") |
| Transport height | 3.55m (11' 7") | 3.6m (11' 10") |
| Working width | 18.3m (60') | 18.3m (60') |
| Working length | 20.05m (65' 10") | 20.05m (65' 10") |
| Working height | 7.89m (25' 11") | 7.89m (25' 11") |
- Output Potential: up to 650 tph (715 US tph)
- 2 x double deck screenboxes
- Patent pending drive system to switch between 2 and 4 bearing arrangements
- Radio controlled tipping grid
- Integrated high capacity variable speed belt feeder
- Heavy duty single shaft screenboxes with adjustable stroke, angle and speed
- Hydraulic screen tensioning (bottom deck)
- Screen walkway and access ladder
- Hydraulic folding conveyors with excellent stockpiling capacity
