Powerscreen 1500 Maxtrak
The new Powerscreen® 1500 Maxtrak is one of the largest mobile cone crushers on the market. Specifically developed for larger users, the plant can accept an all in feed from a primary crusher to produce large volumes of aggregate.
With the Powerscreen® 1500 Automax® cone crusher, operators benefit from hydraulic overload protection, a large throughput, excellent product cubicity, and a high reduction ratio.
Powerscreen 1500 Maxtrak
Check out the Powerscreen 1500 Maxtrak
specifications and features.
| Powerscreen 1500 Maxtrak | |
|---|---|
| Weight (Est) | 90,000kgs (198,500lbs) |
| Transport Width | 3.5m (11'6") |
| Transport Length | 21.9m (71'10") |
| Transport Height | 3.8m (12'6") |
| Working Width | 5.1m (16'9") |
| Working Length | 24.3m (79'9") |
| Working Height | 6.3m (20'8") |
* All information subject to machine configurations & specifications ordered.
** Powerscreen reserves the right to change specifications without prior notice.
- Output Potential: up to 950 tph (1047 US tph)*
- Renowned Automax® crusher technology
- Excellent product shape
- High reduction ratio
- Cone feed box level control to maintain choke feeding
- Hydraulic crusher setting
- Cone overload protection
- Heavy duty chassis and track frame
- Large feed hopper with folding sides, wear resistant liners and crash box
- Feed conveyor folds for maintenance and removes for transport
- Metal detector
- Dust suppression system
- Electric refuelling pump
- Plant lighting
- Intelligent PLC control system
- Economical to operate with a highly efficient direct drive system
Image Gallery
