Powerscreen H5163
The adjustable elliptical throw combines linear and circular amplitude producing an aggressive screening action. Powerscreen® H products are especially effective for scalping after a primary impact or jaw crusher and really have outstanding performance when screening out specific small sizes.
Powerscreen H5163
Check out the Powerscreen H5163
specifications and features.
| H5163 | |
|---|---|
| Weight (Est) | 36,500kgs (80,469lbs) |
| Transport Width | 3m (9'10") |
| Transport Length | 17.87m (58'7") |
| Transport Height | 3.4m (11'2") |
| Working Width | 16.32m (53'7") |
| Working Length | 18.6m (61') |
| Working Height | 4.63m (15'2") |
| Screenunit | 6.1m x 1.8m (20'x6') |
- Output potential up to: H5163: 600 tph (661 US tph)
- High capacity variable speed direct feed belt feeder
- Heavy duty triple shaft screenboxes with adjustable stroke
- Oil bath screenbox bearing lubrication
- Elliptical throw (adjustable 16-19mm/0.55-0.75″)
- Hydraulic folding stockpiling conveyors
- Screen walkway and access ladder
- Diesel hydraulic power unit
- Heavy duty, low ground pressure tracks
- Engine protection and shut down system
