Powerscreen 1300 Maxtrak
The Powerscreen® 1300 Maxtrak is a medium to large sized track mobile cone crusher which is ideally suited to secondary applications such as taking an “all in-feed” from a primary crusher. Based around the 1300 Automax® cone crusher, the plant excels in the production of sub-base or aggregates, providing excellent cubicity, throughput and reduction ratios.
Powerscreen 1300 Maxtrak
Check out the Powerscreen 1300 Maxtrak
specifications and features.
| Powerscreen 1300 Maxtrak | |
|---|---|
| Weight (Est) | 46,300kgs (102,100lbs) |
| Transport Width | 3m (9'10") |
| Transport Length | 15.3m (50'2") |
| Transport Height | 3.8m (12'6") |
| Working Width | 3.0m (9'10") |
| Working Length | 15.4m (50'6") |
| Working Height | 4.5m (14'9") |
* All information subject to machine configurations & specifications ordered.
** Powerscreen reserves the right to change specifications without prior notice.
- Output Potential: up to 350 tph (386 US tph)
- Renowned Automax® crusher technology
- Excellent product shape
- High reduction ratio
- Hydraulic crusher setting
- Cone overload protection
- Heavy duty chassis and track frame
- Metal detector
- Cone feed box level control to maintain choke feeding
- Dust suppression system
- Economical to operate with a highly fuel efficient direct drive system
