Powerscreen Chieftain 1700
The Powerscreen® Chieftain 1700 is a mid-sized track mobile screen aimed at end users requiring high volumes of finished products in applications including topsoil, coal, crushed stone, recycling, iron ore, sand, and gravel. User benefits include a quick set-up time, drop down the tail conveyor and screen mesh access system to aid screen media changes and a transverse power unit arrangement to simplify servicing.
Powerscreen Chieftain 1700
Check out the Powerscreen Chieftain 1700
specifications and features.
| Track (2 Deck) | Wheel (2 Deck) | Track (3 Deck) | Wheel (3 Deck) | |
|---|---|---|---|---|
| Weight (Est) | 27,000kgs (59,524lbs) | 24,700kgs (54,340lbs) | 29,400kgs (64,815lbs) | 27,500kgs (60,627lbs) |
| Transport Width | 3m (9'9") | 3m (9'9") | 3m (9'9") | 3m (9'9") |
| Transport Length | 16.6m (54'5") | 16.6m (54'5") | 16.58m (54'4") | 16.58m (54'4") |
| Transport Height | 3.33m (10'11") | 3.8m (12'6") | 3.42m (11'2") | 3.85m (12'8") |
| Working Width | 17.23m (56'10") | 17.23m (56'10") | 17.45m (57'3") | 17.45m (57'3") |
| Working Length | 17.3m (56'6") | 17.3m (56'6") | 16.61m (54'6") | 16.61m (54'6") |
| Working Height | 5.84m (19'2") | 5.84m (19'2") | 5.84m (19'2") | 5.84m (19'2") |
| Screenunit | 4.8m x 1.5m (16'x5') | 4.8m x 1.5m (16'x5') | 4.8m x 1.5m (16'x5') | 4.8m x 1.5m (16'x5') |
* All information subject to machine configurations & specifications ordered.
** Powerscreen reserves the right to change specifications without prior notice.
- Output potential up to 600 tph (661 US tph)
- 2 or 3 deck
- Radio controlled tipping grid
- Integrated high capacity variable speed belt feeder
- Grease filled 2-bearing screenbox
- Hydraulic screen angle adjustment
- Hydraulic screen tensioning
- Screen walkway and access ladder
- On board hydraulically folding conveyors with excellent stockpiling capacity
- Patented fully mounted hydraulic folding auxiliary stockpile conveyor (3 deck)
- Engine protection shutdown system
