Powerscreen Chieftain 2400
The Powerscreen® Chieftain 2400 / Chieftain 2400S is the largest mobile screen in the range aimed at mining, quarrying and recycling operators who require high volumes of finished sand, gravel, coal, and crushed stone. Ruggedly designed, the Chieftain 2400 / Chieftain 2400S features a hopper suited to direct feeding from a crusher, an oversized heavy duty screen unit and a 4th auxiliary conveyor for recirculating material for secondary reduction and re-screening.
Powerscreen Chieftain 2400
Check out the Powerscreen Chieftain 2400
specifications and features.
| Powerscreen Chieftain 2400 | |
|---|---|
| Weight (Est) | 39,000kgs (85,980lbs) |
| Transport Width | 3m (9'10") |
| Transport Length | 15.65m (51'5") |
| Transport Height | 3.6m (11'10") |
| Working Width | 15.36m (50'5") |
| Working Length | 17.35m (56'11") |
| Working Height | 6.45m (21'2") |
| Screenunit | 6.1m x 1.8m (20'x6') |
- Output potential up to 700 tph (771 US tph)
- Oil bath lubricated 2 bearing, 3 deck screen box
- Hydraulic screen angle adjustment
- Screen walkway and access ladder
- Direct feed hopper
- On board conveyors with excellent stockpiling capacity
- Engine protection shutdown system
